在华为交换机上做基于IP段的流量限速

admin
路由交换
2024-10-30
143

华为交换机用流策略根据IP限速

在华为交换机上做基于IP段的流量限速第1张

根据 IP 地址进行限速

对IP地址为192.168.1.10的PC限速，带宽限制为4M。
system-view
[HUAWEI] acl 2000
[HUAWEI-acl-basic-2000] rule permit source 192.168.1.100.0.0.0
[HUAWEI-acl-basic-2000] quit
[HUAWEI] traffic classifier c1
[HUAWEI-classifier-c1] if-match acl 2000
[HUAWEI-classifier-c1] quit
[HUAWEI] traffic behavior b1
[HUAWEI-behavior-b1] car cir 4096
[HUAWEI-behavior-b1] quit
[HUAWEI] traffic policy p1
[HUAWEI-trafficpolicy-p1] classifier c1 behavior b1
[HUAWEI-trafficpolicy-p1] quit
[HUAWEI] interface gigabitethernet 0/0/1
[HUAWEI-GigabitEthernet0/0/1] traffic-policy p1 inbound

acl 3001
rule permit ip destination 1.1.1.1 0.0.0.0
rule permit ip source 1.1.1.1 0.0.0.0

=============================================

企业网用户的IP为10.0.0.2/24，通过Switch连接Internet。Switch为运营商设备。企业网用户只租用了1Mbps的上行带宽和2Mbps的下行带宽。

图1 普通CAR配置组网

配置思路
流量监管功能是通过QoS命令行实现。本案例中，用户采用固定IP，因此可以通过匹配用户IP地址的方法匹配用户流量，并对其做流量监管。

配置步骤

# 配置ACL规则匹配源IP为10.0.0.2的流量
    <H3C> system-view
    [H3C] acl number 3001
    [H3C-acl-adv-3001] rule permit ip source 10.0.0.2 0
    [H3C-acl-adv-3001] quit

# 配置ACL规则匹配目的IP为10.0.0.2的流量
    [H3C] acl number 3002
    [H3C-acl-adv-3002] rule permit ip destination 10.0.0.2 0
   [H3C-acl-adv-3002] quit

# 配置流分类，匹配ACL规则3001，即匹配源IP为10.0.0.2的流量
    [H3C] traffic classifier source_hostA
    [H3C-classifier-source_hostA] if-match acl 3001
    [H3C-classifier-source_hostA] quit

# 配置流分类，匹配ACL规则3002，即匹配目的IP为10.0.0.2的流量
    [H3C] traffic classifier destination_hostA
    [H3C-classifier-destination_hostA] if-match acl 3002
    [H3C-classifier-destination_hostA] quit

# 配置流行为，用于对上行流量进行流量监管，速率为1000kbps
    [H3C] traffic behavior uplink
    [H3C-behavior-uplink] car cir 1000
    [H3C-behavior-uplink] quit

# 配置流行为，用于对下行流量进行流量监管，速率为2000kbps
    [H3C] traffic behavior downlink
    [H3C-behavior-downlink] car cir 2000
    [H3C-behavior-downlink] quit

# 配置QoS策略，用于端口入方向，即用户的上行方向
    [H3C] qos policy uplink
    [H3C-qospolicy-uplink] classifier source_hostA behavior uplink
    [H3C-qospolicy-uplink] quit

# 配置QoS策略，用于端口出方向，即用户的下行方向
    [H3C] qos policy downlink
    [H3C-qospolicy-downlink] classifier destination_hostA behavior downlink
    [H3C-qospolicy-downlink] quit

# 在端口上下发QoS策略，匹配出入方向的流量
    [H3C] interface GigabitEthernet 3/0/1
    [H3C-GigabitEthernet3/0/1] qos apply policy uplink inbound
    [H3C-GigabitEthernet3/0/1] qos apply policy downlink outbound

=======================================

S系列交换机（S1700除外）和E系列交换机基于IP网段配置限速

是通过ACL和MQC实现的，关键配置如下：

基于源地址

system-view //进入系统视图

[HUAWEI] acl 3000 //创建ACL

[HUAWEI-acl-adv-3000] rule permit ip source 192.168.1.0 0.0.0.255 //通过配置规则（rule）匹配数据流

[HUAWEI-acl-adv-3000] quit

[HUAWEI] traffic classifier c1 //创建流分类

[HUAWEI-classifier-c1] if-match acl 3000 //匹配ACL

[HUAWEI-classifier-c1] quit //退出

[HUAWEI] traffic behavior b1 //创建流行为

[HUAWEI-behavior-b1] car cir 4000 pir 10000 green pass //配置流策略做限速

[HUAWEI-behavior-b1] quit

[HUAWEI] traffic policy p1 //创建流策略

[HUAWEI-trafficpolicy-p1] classifier c1 behavior b1 //匹配流分类和流行为

[HUAWEI-trafficpolicy-p1]quit

[HUAWEI] interface ethernet 0/0/2

[HUAWEI-Ethernet0/0/2] traffic-policy p1 inbound //在接口Eth/0/2(数据流进入设备的接口）入方向上调用流策略p1

[HUAWEI-Ethernet0/0/2] quit

基于目的地址

acl number 3200

rule 5 permit ip destination 192.168.0.0 0.0.255.255

rule 10 permit ip source 192.168.0.0 0.0.255.255

traffic classifier cvpn operator or

if-match acl 3200

traffic behavior bvpn

car cir 15000 pir 15000 cbs 1875000 pbs 1875000 mode color-blind green pass yellow pass red discard

traffic policy pvpn match-order config

classifier cvpn behavior bvpn

vlan 3

traffic-policy pvpn outbound

vlan 7

traffic-policy pvpn outbound

————————————————

原文链接：https://blog.csdn.net/u011775882/article/details/120460778

===================================================

Qos-限速实例根据不通的IP地址来限速

acl number 3999

rule 0 permit ip source 10.88.1.8 0

acl number 3998

rule 0 permit ip source 10.88.1.9 0

traffic classifier ACL3999 operator and

if-match acl 3999

traffic classifier ACL3998 operator and

if-match acl 3998

traffic behavior 7M //流量模板

car cir 7000 cbs 437500 ebs 0 green pass red discard yellow pass

traffic behavior 4M

car cir 4000 cbs 250000 ebs 0 green pass red discard yellow pass

qos policy LIMIT

classifier ACL3999 behavior 7M

classifier ACL3998 behavior 4M

interface GigabitEthernet1/0/20

qos apply policy LIMIT inbound

————————————————

原文链接：

https://blog.csdn.net/eighteenxu/article/details/80284334

Qos限速、流量监管、流量整形原理和实验（华为设备）

原文链接：https://blog.csdn.net/tushanpeipei/article/details/112201996

==============================================

配置接口限速

在接口视图下执行命令qos lr inbound cir cir-value [ cbs cbs-value ]

在接口视图下执行命令qos lr outbound cir cir-value [ cbs cbs-value ]

使用流策略进行限速

（1）根据IP地址进行限速

[HUAWEI] acl 2000

[HUAWEI-acl-basic-2000] rule permit source 192.168.1.10 0.0.0.0

[HUAWEI] traffic classifier c1

[HUAWEI-classifier-c1] if-match acl 2000

[HUAWEI] traffic behavior b1

[HUAWEI-behavior-b1] car cir 4096 //带宽限制为4M

[HUAWEI] traffic policy p1

[HUAWEI-trafficpolicy-p1] classifier c1 behavior b1

[HUAWEI-GigabitEthernet0/0/1]traffic-policy p1 inbound

（2）根据IP地址和协议进行限速

[HUAWEI] acl 3000

[HUAWEI-acl-adv-3000] rule permit tcp destination-port eq 80 source 192.168.1.0 0.0.0.255

[HUAWEI] traffic classifier c1

[HUAWEI-classifier-c1] if-match acl 3000

[HUAWEI] traffic behavior b1

[HUAWEI-behavior-b1] car cir 10240 //限速10M

[HUAWEI] traffic policy p1

[HUAWEI-trafficpolicy-p1] classifier c1 behavior b1

[HUAWEI-GigabitEthernet0/0/1] traffic-policy p1 inbound

使用流策略对报文进行过滤

（1）禁止指定主机访问网络

[HUAWEI] acl 2000

[HUAWEI-acl-basic-2000] rule deny source 192.168.1.10 0.0.0.0

[HUAWEI] traffic classifier c1

[HUAWEI-classifier-c1] if-match acl 2000

[HUAWEI] traffic behavior b1

[HUAWEI-behavior-b1] deny

[HUAWEI] traffic policy p1

[HUAWEI-trafficpolicy-p1]classifier c1 behavior b1

[HUAWEI] interface gigabitethernet 0/0/1

[HUAWEI-GigabitEthernet0/0/1]traffic-policy p1 inbound

（2）过滤指定应用协议报文

[HUAWEI] acl 3000

[HUAWEI-acl-adv-3000]rule deny tcp destination-port eq 25

[HUAWEI-acl-adv-3000]rule deny tcp destination-port eq 110

[HUAWEI-acl-adv-3000]rule deny tcp destination-port eq 80

[HUAWEI] traffic classifier c1

[HUAWEI-classifier-c1] if-match acl 3000

[HUAWEI] traffic behavior b1

[HUAWEI-behavior-b1] deny

[HUAWEI] traffic policy p1

[HUAWEI-trafficpolicy-p1] classifier c1 behavior b1

[HUAWEI-GigabitEthernet0/0/1]traffic-policy p1 inbound

使用流策略配置流量统计

（1）配置指定主机的统计信息

[HUAWEI] acl 4000

[HUAWEI-acl-L2-4000] rule permit source-mac 0000-0000-0003 ffff-ffff-ffff

[HUAWEI] traffic classifier c1

[HUAWEI-classifier-c1] if-match acl 4000

[HUAWEI] traffic behavior b1

[HUAWEI-behavior-b1] statistic enable

[HUAWEI] traffic policy p1

[HUAWEI-trafficpolicy-p1] classifier c1 behavior b1

[HUAWEI-GigabitEthernet0/0/1]traffic-policy p1 inbound

[HUAWEI-GigabitEthernet0/0/1]traffic-policy p1 outbound

（2）配置对ICMP报文进行统计

[HUAWEI] acl 3000

[HUAWEI-acl-adv-3000]rule 0 permit icmp source 192.168.1.1 0 destination 192.168.2.1 0

[HUAWEI-acl-adv-3000]rule 5 permit icmp source 192.168.2.1 0 destination 192.168.1.1 0

[HUAWEI] traffic classifier c1

[HUAWEI-classifier-c1] if-match acl 3000

[HUAWEI] traffic behavior b1

[HUAWEI-behavior-b1] statistic enable

[HUAWEI] traffic policy p1

[HUAWEI-trafficpolicy-p1] classifier c1 behavior b1

[HUAWEI-GigabitEthernet0/0/1] traffic-policy p1 inbound

[HUAWEI-GigabitEthernet0/0/1] traffic-policy p1 outbound

（3）配置对ARP报文进行统计

[HUAWEI] traffic classifier arp-request

[HUAWEI-classifier-arp-request]if-match l2-protocol arp

[HUAWEI-classifier-arp-request]if-match source-mac 1111-1111-1111

[HUAWEI-classifier-arp-request]if-match destination-mac ffff-ffff-ffff

[HUAWEI] traffic classifier arp-reply

[HUAWEI-classifier-arp-reply]if-match l2-protocol arp

[HUAWEI-classifier-arp-reply]if-match source-mac 2222-2222-2222

[HUAWEI-classifier-arp-reply]if-match destination-mac 1111-1111-1111

[HUAWEI] traffic behavior b1

[HUAWEI-behavior-b1] statistic enable

[HUAWEI] traffic policy arp-request

[HUAWEI-trafficpolicy-arp-request]classifier arp-request behavior b1

[HUAWEI] traffic policy arp-reply

[HUAWEI-trafficpolicy-arp-reply]classifier arp-reply behavior b1

[HUAWEI-GigabitEthernet0/0/1] traffic-policy arp-request inbound

[HUAWEI-GigabitEthernet0/0/1] traffic-policy arp-reply outbound

（4）查看报文统计信息

display traffic policy statistics interface gigabitethernet 0/0/1 inbound verbose rule-base //显示全局入方向应用流策略后基于匹配规则的报文统计信息

————————————————

原文链接：https://blog.csdn.net/Tony_long7483/article/details/120978662
